ATLAS NG - The 6 GHz universal broadcast analyzer

Our ATLAS NG multipurpose analyzer now comes with 4G/5G signal analyzer (optional), TS and ASI over fiber (optional), DVB-S2x supporting up to 256-APSK... This is all in addition to ATSC 3.0, IPTV, Fiber optic measurements, 3G-SDI, ALP and transport stream, ASI...

MORE INFORMATION ›

Features that redefine what's possible in a broadcast analyzer

4G/5G cellular network measurements

Scan the entire FR1 band, identify and categorize 4G/5G channels, display cell/channel info... The ATLAS NG sets the standard for mobile network analysis and troubleshooting.

SEE THE VIDEO ›

TS-ASI and SDI over fiber (optional)

This option enables ATLAS NG to receive and output transport stream and SDI signals via a dedicated Fiber Optics interface, which is increasingly prevalent in nowaday broadcast environments.

FULL SPECIFICATIONS ›

DISPLAY THE VIDEO ›

6 GHz Spectrum Analyzer with additional functions

Save traces and display max/min hold markers to compare signal variations over time.

Seamless DVB-S2x compatibility

ATLAS NG supports up to 256-APSK modulation schemes, linear and non-linear, with symbol rates up to 80 MSps, and CCM, VCM and ACM modulation schemes with a variety of MODCODs.

REQUEST MORE INFO ›

Native 4k video decoding

ATLAS NG is fully compatible with HEVC H.265 and can also handle flawlessly even the most demanding 10-bit HEVC videos.

GET THE CATALOG ›

High-speed TS-ASI input and output

It includes unique features such as selection and decapsulation of any of the containing PLPs in a T2-MI with a bitrate of up to 200 Mbps.

Wifi 2.4 GHz & 5.7 GHz analyzer

Identify interferences from WiFi and non-WiFi transmitters. ATLAS NG can display real spectrum analyser information and access point data for both 2.4 GHz & 5.7 GHz.

REQUEST MORE INFO ›

Advanced DAB/DAB+ analysis

Includes a comprehensive range of measurements for DAB/DAB+ signals including but not limiting to ETI Recording & Playing, IQ Recording, Full ensemble CBER, Echoes, MER...

Advanced FM analysis

ATLAS NG provides extended and comprehensive analysis of the FM radio signals including the MPX spectrum analysis to detect interfering signals which cannot be seen otherwise
